ATEX LED LINE
ATEX LED LINE is designed for use in potentially hazardous and explosive atmospheres. ZONE 2, 22
ATEX LED LINE WORKING ZONE DEFINITIONS:
ZONE 2 – An atmosphere where a mixture of air and flammable substances (gas, vapor or mist) is not likely to occur in normal operation but, if it does occur, will persist for only a short period.
ZONE 22 – An atmosphere in which an explosive mixture is not likely to occur in normal operation, and if it occurs it will exist only for a short time.
ATEX LED LINE FEATURES:
LOM 13 ATEX 4081 X
CERTIFICATE
IP68 - IK08
INGRESS PROTECTION
24 VDC
VOLTAGE RANGE
- 20 C
MINIMUM WORKING TEMPERATURE
+ 45 C
MAXIMUM WORKING TEMPERATURE
ENGINEERED AND MANUFACTURED BY INPRATEX
For industries that operate within potentially hazardous and explosive atmospheres, InpratEx provides a range of tailored, specialist services.
ATEX LED LINE
Marking:
II 3G Ex mc IIC T6 Gc
II 3D Ex mc IIIC T85ºC Dc
Certificates
LOM 13 ATEX 4081 X | Download pdf
Application
Industrial
Housing
Aluminum, RAL 9010
LED
4000K | 5000h L80B10 | 8000h L55B10 | 13000h L37B10 | 23000h L12B10
Diffuser
Epoxy resin
Ambient Temperature
-20ºC to +45ºC
Power
– ATEX LED LINE 205: 1 W
– ATEX LED LINE 210: 1 W
– ATEX LED LINE 305: 2 W
– ATEX LED LINE 310: 2 W
– ATEX LED LINE 405: 3 W
– ATEX LED LINE 410: 3 W
– ATEX LED LINE 505: 4 W
– ATEX LED LINE 510: 4 W
– ATEX LED LINE 605: 5 W
– ATEX LED LINE 610: 5 W
– ATEX LED LINE 705: 6 W
– ATEX LED LINE 710: 6 W
– ATEX LED LINE 805: 7 W
– ATEX LED LINE 810: 7 W
– ATEX LED LINE 905: 8 W
– ATEX LED LINE 910: 8 W
– ATEX LED LINE 1005: 9 W
– ATEX LED LINE 1010: 9 W
– ATEX LED LINE 1105: 10 W
– ATEX LED LINE 1110: 10 W
– ATEX LED LINE 1205: 11 W
– ATEX LED LINE 1210: 11 W
– ATEX LED LINE 1305: 12 W
– ATEX LED LINE 1310: 12 W
Rated voltage
24V DC
Ingress protection
IP 66/68
IK08
Energy efficiency class
F
Cable entries
Non-replaceable cable, cable length options 5 and 10 m. Other configurations on request.
